The Safety Shield 360º Surround View system, seamlessly calibrates and video merges on the in-cab screen display, the plant can move at any speed without any blurring images occurring.

The system fully records (when the vehicle ignition is on) from all 4 cameras. The system does not record constantly when the ignition is turned off, however it recognises when the vehicle has been hit by another plant vehicle, object or someone attempting to break in. This is achieved through the use of vibration sensors and therefore records the impact despite the ignition being turned off.

The cameras provided with the Safety Shield 360° Surround View system are ultra 190° fish eye WDR (Wide Dynamic Range) cameras.  WDR cameras help give a clearer view at night time when the surrounding light intensity is much lower than daylight intensity which enhances the recordings of the in-cab display in both scenarios.



features

  • Four 190 degrees ultra-wide fish-eye cameras

  • Seamless video merging based on dual core ARM CPU and hardware high efficiency acceleration engine

  • Arbitrary and dynamic 3D mode view angle switching for better surrounding environment observation

  • Independent Fish-eye calibration parameter and algorithm for each camera

  • Pixel statistic engine for real time brightness balance among four channels outside cameras

  • 3D video de-interlacing and noise reduction technology for CVBS signal decoding

  • Support alternative recording media for TF card or USB disk

  • The simplest calibration steps with calibration tape and packing boxand system applicable for almost all types of vehicle which including Buses, Trucks, Lorries, Limousines, Tanks and even Jumbo Jets. Typical length of the vehicle is 5.5m, 6.5m, 10m&13m

  • Smart power managements to save automobile’s battery

  • High video recording resolution up to 1440*960

  • OE quality for main chipset with well protected circuit and devices in order to achieve the best system performance and stability


3d360 camera.png

installation

No specialist installer is required to install the system to the vehicle. The manual and in cab display both clearly explain how to calibrate the system using the simple calibration instructions and what is required throughout the calibration process. The image is then enhanced with a high definition signal output helping to deliver a crystal-clear display of the bird’s eye view.


Example of typical camera configuration for excavator

Screen Shot 2019-05-13 at 14.50.37.png

Screen Shot 2019-05-13 at 14.54.19.png

3D 360° surround view.
